The polyamide overcoated wires demonstrate the same
properties as the above wires without polyamide coating. What’s more, because of the polyamide coating, these wires’ mechanic properties are improved greatly in friction modulus, abrasive resistance, bending properties ect.
-The polyamide overcoated wires demonstrate the same properties as the above wires without polyamide coating.
-What's more, because of the polyamide coating, these wires' mechanic properties are improved greatly in friction modulus, abrasive resistance, bending properties ect.
Product size range: 0.04mm-4.0mm
Product types: Class 130-240
Executive standards: IEC, JIS, DIN and NEMA
Management Systems:
ISO 9001: 2008
ISO TS 16949
ISO 14001: 2004
| Thermal level | Specifications range | Standard | |||||
| code | level | mm | AWG | IEC | GB/T | NEMA | JIS |
| B | 130 | 0.04-1.8 | 13#-46#* | 60317-19 | 6109.9 | MW28-C | C3202 |
| F | 155 | 60317-21 | 6109.11 | MW80-C | |||
| H | 180 | 60317-51 | 6109.23 | MW83-C | |||
Note:“*”for approximate American wire gage
