Aluminum plate 1050 is also known as pure aluminum, in the series in 1000 series belongs to all the alumina quantity of a maximum number of series. Purity can achieve 99.00% above.
Alloy Number: 1050,
Temper: O, H12, H14, H16, H18, H24,
Surface treatment: Mill finish, with blue PVC films or paper-interleaved
Thickness: 0.2mm – 6mm (CC Material), 6mm – 200mm; (DC Material)
Maximum width 2600mm; Maximum length: 12 Meters;
Packaging: Standard seaworthy export packing;
For 1 x 20FCL can load 20 to 25 Tons.
Standard size: 1000mm x 2000mm; 4’x8’, 1219mm x 2438mm, 1500mm x 3000mm;
1050 Aluminum Sheet Chemistry Composition / A1050 Date Sheet:
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Al |
|---|---|---|---|---|---|---|---|---|---|---|
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | 99.5 |
1050 Aluminum Sheet Mechanical Properties / Properties of alloy 1050:
| Temper | Anti –tensile strength N/m㎡ | Elongation rate（%） | Dimension Control | surface |
|---|---|---|---|---|
| 1050-O | 78Mpa (8Ksi -12Ksi) | 35 (above 2.5 Ksi) | Qualified | Qualified |
| 1050-H12 | 95Mpa (11Ksi - 16Ksi) | 18 (above 9 Ksi) | Qualified | Qualified |
| 1050-H14 / H24 | 123Map (12Ksi - 17Ksi) | 7 (above 9 Ksi) | Qualified | Qualified |
| 1050-H18 | 140 Map (above 16Ksi) | 4 (above 10Ksi) | Qualified | Qualified |
