Aluminum Coil 5A03

5A03 aluminum sheet is the most commonly used material in the construction field, and also belongs 5 series Al-Mg antirust alloy. In terms of composition, the Mg content of 5A03 aluminum is slightly higher than that of 5754 aluminum alloy, so 5A03 aluminum sheet corrosion resistance and tensile strength are higher than those of 5754 alloy. And due to the addition of a small amount of Si, 5A03 aluminum alloy has better weldability than 5754 and 5A02 alloy.

Alloy: 5A03

Temper: O/H22/H32/H34/H36/H38

Thickness: 0.3mm to 8.0mm

Width: 500mm to 2600mm

Max width: 2600mm;  ID: 508mm, OD: 1800mm,

Surface: mill finish surface, bright, polished surface, with blue PVC films or paper-interleaved;

5A03 Aluminum Plate Features:

Significant Weldability. Due to the Si content, 5A03 aluminum sheet has better weldability than 5754, 5A02 alloy, and is suitable for gas welding, argon arc welding, spot welding and roll welding, etc. At the same time, a small amount of Si also increases the strength between welds, and reduces the crack tendency.

Strong Weather Resistance. Even below 0℃, 5A03 aluminum sheet strength won’t decrease with the decrease of temperature, but will increase, with excellent fatigue strength. There's no low temperature brittleness.

Mechanical Proprties. 5A03 aluminum sheet tensile strength σb (MPa)≥172, elongation δ5 (%)≥12,conditional yield strength σ0.2 (MPa)≥81.

5000 Series Alloy (Generally called Al-Mg Alloy, the Mg is used as main alloy element)


5005 5052 5083 5086 5182 5754 5154 5454 5A05 5A06


O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34
H16/H26/H36 H18/H28/H38 H114/H194, etc.


Thickness≤170mm; Width≤2200mm ; Length≤12000mm


Marine Grade Plate, Ring-Pull Can End Stock, Ring-Pull Stock, Automobile
Body Sheets, Automobile Inside Board, The Protective Cover On Engine.


All the advantages of normal aluminium alloy, high tensile strength & yield strength,
good corrosion resistant performance, well welding property, well fatigue strength,
and suitable for anodic oxidation.
