Aluminum Coil 5052 A95052 AlMg2.5

5052 aluminum coil is a typical Al-Mg antirust alloy, which is famous for its extremely high fatigue strength, excellent formability and weldability. Among them, the most commonly used 5052-h32 aluminum coil is the 5052 aluminum coil that is processed and hardened, as well as then subjected to low temperature treatment or heat to obtain stable mechanical properties.

Alloy: 5052

Temper: O/H22/H32/H34/H36/H38

Thickness: 0.3mm to 8.0mm

Width: 500mm to 2600mm

Max width: 2600mm;  ID: 508mm, OD: 1800mm,

Surface: mill finish surface, bright, polished surface, with blue PVC films or paper-interleaved;

Mainly market:  Europe, India, Iran, Pakistan, Thailand, Mexico, USA and so on.

It is widely used for ship engine bases, ship decks, ship sides, bottom outer plates, etc., covering the hulls of yachts and cruise ships, etc.

5052 Aluminum Coil Features:

Excellent Corrosion Resistance. Corrosion resistance is the typical property of 5052 aluminum coil. It is very effective to resist the corrosion of seawater, atmosphere, gasoline and other chemical.

Mechanical Properties. Take 5052-h32 aluminum coil as example, 5052-H32 tensile strength (Rm/Mpa) is 220-260, proof strength (Rp0.2/Mpa) is 130, percentage elongation after fracture is 5, and hardness is 61 HB.

Other Features. Marine grade aluminum 5052 for diesel tanks with high fatigue strength advantages is more suitable than 5083 marine aluminum. Besides, 5052 aluminum coil also has excellent formability, weldability, weather resistance and excellent polishing effect,etc.


5000 Series Alloy (Generally called Al-Mg Alloy, the Mg is used as main alloy element)

Alloy

5005 5052 5083 5086 5182 5754 5154 5454 5A05 5A06

Temper

O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34
H16/H26/H36 H18/H28/H38 H114/H194, etc.

Specification

Thickness≤170mm; Width≤2200mm ; Length≤12000mm

Application

Marine Grade Plate, Ring-Pull Can End Stock, Ring-Pull Stock, Automobile
Body Sheets, Automobile Inside Board, The Protective Cover On Engine.

Feature

All the advantages of normal aluminium alloy, high tensile strength & yield strength,
good corrosion resistant performance, well welding property, well fatigue strength,
and suitable for anodic oxidation.
